Key Features
• Splash lubricated design
• Stainless-steel braided discharge hose
• Large canister intake filter
• Oil level sight indicator
• 14 HP 420cc OHV engine
• Electric start (battery and cables not included)
• Powder-coated ASME-coded 30-gallon receiver tank
• 3/16" base plate to reduce vibration
• 16-gauge powder-coated two-piece belt guard
• Removable base plate for flexible installation
• Regulator with dual pressure gauges (tank and outlet)
• ASME safety valves
• 16.5" flywheel
• Tank drain valve
• 150 PSI maximum-rated regulator
Specifications
|
Parameter |
Value |
|
CFM @ 175 PSI |
29.0 |
|
Displacement / Engine |
420cc OHV |
|
Compressor Type |
Two-stage, Cast Iron |
|
Tank Capacity |
30 gallons |
|
Engine Idle Control |
Pneumatic |
|
Net Weight |
416 lbs |
|
Shipping Weight |
480 lbs |
|
Dimensions (L × W × H) |
38" × 23" × 46" |
